Luuk Van Keeken: NIR Introduction and Graph Tracing With Torch.fx

Because the neuromorphic ecosystem relies on fragmented, highly specific software libraries (like Norse, snnTorch, and Rockpool) and heavily restricted hardware (like Intel Loihi and SpiNNaker), moving a trained model from one environment to another is notoriously difficult. In this session, Luuk van Keeken and Jens E. Pedersen explore how the Neuromorphic Intermediate Representation (NIR) resolves this “all-to-all” translation problem, and demonstrate how utilizing torch.fx makes extracting graphs from PyTorch-based spiking models significantly more robust.

Key Takeaways

• NIR acts as a universal translator: By providing a unified understanding of what constitutes a basic neuromorphic primitive (e.g., a Leaky Integrate-and-Fire neuron), NIR allows researchers to export a model from one framework and cleanly compile it for vastly different hardware targets.
• Manual PyTorch tracing is fragile: Older methods of exporting PyTorch SNNs required manually replacing the forward functions of modules to record their edges. This approach frequently broke when a model utilized non-module Python operations, like standard mathematical addition or division.
• torch.fx captures functional dependencies: The torch.fx toolkit solves the tracing problem by generating a structured computational graph that recognizes both object-oriented module calls and purely functional code execution, ensuring no operational steps are lost.
• Simplifying the graph via primitives: When torch.fx captures a functional addition operation, NIR can streamline the output graph by simply merging the input arrows directly into the subsequent node, matching standard neuromorphic data flows.
• Translation still requires specific mapping: While nir.torch effectively captures the graph shape, differing frameworks still parameterize neurons differently (e.g., varying assumptions about time steps). Individual framework mappers must carefully adjust parameters to align with NIR’s exact mathematical definitions.

What Was Built / Demonstrated

The session centered on live-refactoring the nir.torch extraction pipeline. By replacing legacy tracing workarounds with a custom torch.fx Tracer class, the developers successfully captured the internal graph of a Norse PyTorch module.

The demonstration showed how the new tracer automatically identified the sequential module dependencies alongside bare functional calls (like addition). By providing a dictionary mapping Norse-specific modules (like LIFBoxCell) to NIR primitives, the extracted PyTorch graph was successfully parsed into a clean, hardware-agnostic intermediate representation without having to parse the messy internal dynamics of the leaky integrator itself.

What This Means for Neuromorphic Computing

Without a common representation standard, bench-marking neuromorphic hardware is nearly impossible. If a researcher wants to compare the energy efficiency of SpiNNaker against Loihi, they traditionally have to completely rewrite their neural network from scratch using disparate, framework-specific APIs.

By stabilizing the PyTorch-to-NIR extraction pipeline using torch.fx, researchers can author models in their preferred Python environment and instantly export a strict mathematical representation. This lowers the barrier to entry for neuromorphic deployment, allowing algorithms to be seamlessly shared, verified, and compared across the industry’s varied edge devices.
